SUS304 , SUS316L DW Series Balloon Flower Mesh belt (Dryer Oven Machine)for food stuff , pharmaceutical

Proface

DW series belt drier will have to deal with the material through the appropriate accessories, such as star, swinging with the case, mill or granulator, distribution on the conveyor belt, conveyor belt through one or several heating unit of channels, each heating units are equipped with air heating and circulation system, each channel has one or more rows of wet system, the conveyor belt through the hot air from above or from down to up through the conveyor belt material, so that the material can dry evenly.

Principle

The materials are uniformly distributed on the mesh-belt by the material feeder. The mesh-belt generally adopts 12-60 mesh stainless steel mesh and it is drawn by a transmission device and move inside the dryer. The dryer is composed of several sections. For each section the hot air is circulated separately. Part of exhausted gas is exhausted by a special moisture exhaust blower. The waste gas is controlled by an adjustment valve. The hot air passes through the mesh-belt covered with bring water material away. The mesh-belt moves slowly, running speed can be freely adjusted according to the material property. The final products after the drying process will fall into the material collector continuously. The top and low circulation units can be freely equipped according to client requirement;

The characteristics of the mesh belt dryer:

1, It can adjust the volume of air, heating temperature, residence time and heating rate in order to obtain the best drying effect;
2, The flexible configuration can use the washing system of screen belt and the material cooling system;
3, Most of the air circulation utilization, high energy savings;
4, The unique points of wind device, make the hot air distribution more uniform, ensure consistent product quality;
5, Heat source can use steam, heat conduction oil, electricity or coal (oil) form a complete set of hot blast stove;

Feature

◆ Most hot air is circulated in the cabinet, heat efficiency is high and save energy.
◆ Use forced ventilation and cross flow type drying principle, there are air distribution plates in the cabinet and material is dried uniformly.
◆ Low noise, stable operating, self-control temperature and convenience to install and maintain.
◆ Wide scope of application, it is suitable for all kinds material, and is the general type drying equipment
◆ Common control(Button control)or PLC and touch screen control are on request
◆ Temperature controllable ;
◆ Store memory of work-program mode and technological parameter and printing function (According to client’s requirements)

Application :

De-watering vegetable, particle feed, gourmet powder, shredded coconut stuffing, organic color, compound rubber, medicine product, medicine material, small wooden product, plastic product, aging and solidification for the electronic component and device..

The materials are uniformly distributed on the mesh-belt by the material feeder. The mesh-belt generally adopts 12-60 mesh stainless steel mesh and it is drawn by a transmission device and move inside the dryer. The dryer is composed of several sections. For each section the hot air is circulated separately. Part of exhausted gas is exhausted by a special moisture exhaust blower. The waste gas is controlled by an adjustment valve. The hot air passes through the mesh-belt covered with bring water material away. The mesh-belt moves slowly, running speed can be freely adjusted according to the material property. The final products after the drying process will fall into the material collector continuously. The top and low circulation units can be freely equipped according to client requirement;
