Hot Air Circulating Food Stuff Dryer Oven Machine 100 - 200℃ High Temperature

Hot Air Circulating Food Stuff Dryer Oven Machine 100 - 200℃ High Temperature

  • High Light

    industrial drying ovens


    air circulating oven

  • Metal Material
  • Heating Source
    Steam / Electrical / Natural Gas / Diesel / Etc;
  • Document
    FAT/ IQ / OQ / PQ
  • Temp
  • Motor
  • Control System
    PLC+HMI / Button Control
  • Place of Origin
  • Brand Name
  • Certification
    CE / UL / SGS / EAC / CR – TU
  • Model Number
  • Minimum Order Quantity
    1 set
  • Price
  • Packaging Details
  • Delivery Time
  • Payment Terms
    L/C, T/T
  • Supply Ability

Hot Air Circulating Food Stuff Dryer Oven Machine 100 - 200℃ High Temperature

CT-C  Hot Air Circulating Drying Oven Machine (Hot air drying oven ) (Hot air oven )( Hot air circulating oven, Hot air circulating drying machine


CT-C series hot air circulating oven adopts noise elimination and thermal stable axial flow fan and automatic temperature control system. The entire circulation system is enclosed to make that the heat efficiency of the drying oven increases from 3-7% of the traditional drying oven to 35-40% of the present one. The highest heat efficiency can be up to 50%. The successful design of CT-C hot air circulating oven makes that the hot air circulating drying oven in our country reach the advanced level in the world. It saves energy and increases the economic benefit. In 1990, the medical management bureau of the State issued the industry standard and the uniform type is RXH.



1. Options of heat source: steam, electricity, or far infrared, or both steam electricity.

2. Drying temperature: steam heating 50-130˚C, Max.140˚C.

3. Electricity and far infrared:50-300˚C.Automatic control system and computer control system on request.

4. Commonly using steam pressure 0.2-0.8MPa(2-8 bar).

5. For CT-C-I, electric heated, rated power consumption:15kW, real consumption : 5-8kW/h.

6. The special requirements should be indicated at the time of order.

7. For operation temperature of over 140˚C or less than 60˚C, please indicate when order.

8. The ovens and baking trays made by our factory are uniform in dimensions, and can be exchanged each other.

9. Baking plate dimensions:460x640x45mm.

RXH-5-C RXH-14-C RXH-27-C RXH-41-C RXH-54-C
Oldly type CT-C-0 CT-C-I CT-C-II CT-C-III CT-C-IV
Dry quantity
kg/every time
25 100 200 300 400
Power KW 0.45 0.45 0.9 1.35 1.8
Used steam kg/h 5 18 36 54 72
Wind power stere/h 3400 3400 6900 10350 13800
Temperature difference -2 - +2 -2 - +2 -2 - +2 -2 - +2 -2 - +2
Oven plate 24 48 96 144 192
Size (L*W*H) mm 1550*1000*2044 2300*1200*2300 2300*2200*2300 2300*3220*2000 4460*2200*2290
Remarks Single door
Single dolly
Double door Double dolly Double door
four dolly
Double door
Six dolly
Four door
Eight do



Application :

This drying oven is suitable for material and product hot solidification and dry de-watering in the pharmaceutical, chemical, food, farming side-product, aquatic product, light industries, heavy industries and others industries. Such as: raw material medicine, crude drug, prepared herbal medicine of Chinese traditional medicine, plaster, powder, particle, drinking agent, pill, packing bottle, pigment, dyestuff, dewatering vegetable, dried fruit piece, sausage, plastics, resin, electric component, baking varnish and etc.



Most hot air is circulated in the oven. The heat efficiency is high and the energy is saved. By using the forced ventilating function, there are adjustable air distribution plates inside the oven, the materials can be dried uniformly. The heating source might be steam, hot water, electricity and far infrared, with a wide selection. The whole machine is low in the noise. The operation is in balance. The temperature is controlled automatically. The installation and maintenance are easy. The application is wide. The machine can be used for drying various materials and is a versatile drying equipment.
