| MOQ: | 1 ser |
| Price: | Negotiation |
| Standard Packaging: | Wooden case |
| Delivery Period: | 65 working days |
| Payment Method: | LC , TT |
| Supply Capacity: | 28 SETS/ YEAR |
Working principle:
The powder granule in vessel (fluid bed) appears in the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive is sprayed into the container. It makes the particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.
Features:
l Reduction in the amount of fines and improvement in the flow ability.
l Mixing,granulating and dryig in one container
l Operation under the negative pressure to avoid dust and contamination
l No dead space, easy to disassemble and clean, complying with GMP standards.
l Pulse blow back filter technology
Options:
l Exhaust air dust detector and air flow rate monitoring
l Inlet air dehumidification
l Exhaust air secondary filteration
l Explosion proof design
l Top plate lifting& lowering system
l Product bowl with mixing function
l WIP system
l Solution spray system
Technical parameters:
| Item | Model | FL-3 | FL-10 | FL-30 | FL-60 | FL-120 | FL-200 | FL-300 | FL-500 | ||||||||
| Material bowl | Volume(L) | 11 | 38 | 120 | 340 | 500 | 650 | 990 | 1850 | ||||||||
| Capacity | Minimuim(kg/batch) | 1.2 | 5 | 15 | 30 | 60 | 100 | 150 | 350 | ||||||||
| Maximum(kg/batch) | 3 | 10 | 30 | 60 | 120 | 200 | 300 | 500 | |||||||||
| Air fan power(kw) | 4 | 5.5 | 7.5 | 11 | 18.5 | 30 | 37 | 55 | |||||||||
| Power supply(V.Hz) | 380V,50Hz,3 phase 4 wires | ||||||||||||||||
| Steam pressure | 0.2-0.4 | ||||||||||||||||
| Steam consumption | 20 | 55 | 160 | 160 | 300 | 380 | 570 | 488 | |||||||||
| Compressed air pressure(Mpa) | 0.4-0.6 | ||||||||||||||||
| Compressed air pressure(Mpa) | Pluse blow back | 0.5 | 0.8 | 1 | 1 | 2 | 2.4 | 2.8 | 4.5 | ||||||||
| Cylinder shaking bag | 0.3 | 0.4 | 0.4 | 0.6 | 1 | 1.5 | 1.5 | 2.5 | |||||||||
| Tempeature(°C) | Normal temperature:-120°C automatic adjustment | ||||||||||||||||
| Weight(Kg) | 750 | 1000 | 1000 | 1200 | 1400 | 1900 | 2100 | 2500 | |||||||||
|
|
