SUS304 SUS316 Acrylic Resin Spray Drying Machine , High Speed Food Dryer Machine

Place of Origin CHINA
Brand Name YIBU
Certification CE / UL / SGS / EAC / CR – TU
Model Number LPG
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details Woodencase
Delivery Time 10 WEEKS
Payment Terms L/C, T/T
Supply Ability 20 SETS PER MONTH
Product Details
Metal Material SUS316/SUS304/ CARBON STEEL ,ETC Heating Source Steam / Electrical / Natural Gas / Diesel / Etc
Capacity 10-10000kg Per Hour Water Evaporation 5-5000kg Per Hour
Temp 120-600'C Particle Per Hour
High Light

food dryer machine

,

spray drying equipment

Leave a Message
Product Description

Acrylic Resin   SUS304 SU316 LPG Series High speed Centrifugal Ephedra sinica extract Spray Drying Equipment for foodstuff

Description:

Acrylic Resin Spray dryer drying is the technology most widely used in the liquid technology shaping and in the drying industry. The drying technology is most suitable for producing solid powder or particle products from liquid materials, such as: solution, emulsion, suspension and pumpable paste states ,For this reason, when the particle size and distribution of the ­final products, residual water contents, mass density and the particle shape must meet the precise standard, spray dryer drying is one of the most desired technologies.

Work Principle:

High Speed Centrifugal Spray Dryer Series of LPG is gas-liquid co-current flow drying equipment, using high-speed centrifugal atomizer, the liquid will be atomized into fine droplets, then mix with the hot air from the distributor in the dryer, heat and mass transfer exchanges rapidly during the mixing process. In a very short period of time the liquid become dry powdered products. Production control and product quality control is convenient and reliable. It is widely used in the drying production of different types of liquids materials.

Feature :
The drying speed is high when the material liquid is atomized, the surface area of the material will increase greatly. In the hot-air flow, 95%-98% of water can be evaporated at a moment. The time of completing the drying is only several seconds. This is especially suitable for drying the heat sensitive materials. Its final products own the good uniformity, flow ability & solubility. And the final products are high in purity and good in quality. The production procedures are simple and the operation and control are easy. The liquid with moisture contents of 40-60% (for special materials, the contents might be up to 90%.)can be dried into the powder or particle products once a time. After the drying process, there is no need for smashing and sorting, so as to reduce the operation procedures in the production and to enhance the product purity. The product particle diameters, looseness and water contents can be adjusted through changing the operation condition within a certain range.
ed centrifugal sprayer on the top of the tower, the material liquid will rotate and be sprayed into the extremely fine mist liquid beads. Through very short time of contacting the heat air, the materials can be dried into the final products. The final products will be discharged continuously from the bottom of the drying tower and from the cyclones. The waste gas will be discharged from blower.


  1. YIBU conventional Spray Dryer turns liquid into powder in a highly efficient manner. It is used within fields as diverse as the dairy, food and chemicals industries where it has won renown for its performance. With more than 2,500 spray dryers installed worldwide, YIBU Dryer combines experience and cutting-edge technology into added-value solutions for its customers.
  2. Designed for the specific product to be dried in compliance with a given industry’s standards and requirements, the conventional Spray Dryer produces a fine powder with particle sizes between 20-300 my. It is primarily applied in the chemical industry, but it has also proved valuable in the production of food and dairy products.
  3. Atomization of the concentrate takes place via either a Rotary Atomizer or high-pressure nozzles. The drying air enters through the air disperser at a high velocity, ensuring optimal mixing with the atomized concentrate. Evaporation is instantaneous, taking place as the droplets pass through the drying chamber.
  4. Complete control of moisture content, particle structure, particle size distribution, solubility, and wettability, and retention of natural aromas and flavours.
  5. Unbeatable performance/cost ratio Energy efficient components, continuous and rapid drying, ease of operation and process automation provide complete control over yield and costs.



TypeLPG
52550100150200-3000
Inlet temperature≤ 350°C
Outlet temperature80-90°C
evaporate capacity (kg/h)52550100150200-3000
driving typecompressed air drivemechanical drive
Rotate speed250002200021500180001800015000
diameter of atomizer tray (mm)50120120120150180-340
heating sourceelectricityelectricityelectricity +steam+fuel oil+coal gaselectricity +steamelectricity +steam+fuel oil+coal gasTo be solved by users
Electric-heating power (kw)945608199
Dried powder recovery rate (%)≥ 95≥ 95≥ 95≥ 95≥ 95≥ 95
Installation sizeA(mm)10001290173025002800according to practical needs
B(mm)21003410424553006000
C(mm)23004260464560006700
φ D(mm)10601800213325602860
E1(mm)10501200164021002180
E2(mm)10501200164021002180
F(mm)7501000125017501970
G(mm)5301700175019302080
H(mm)5301300180026003050
I(mm)5301550160017801960
