Stevia LPG Series High speed Centrifugal Spray Drying Equipment for foodstuff

Place of Origin CHINA
Brand Name YIBU
Certification CE / UL / SGS / EAC / CR – TU
Model Number LPG
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details Woodencase
Delivery Time 10 WEEKS
Payment Terms L/C, T/T
Supply Ability 20 SETS PER MONTH
Product Details
Metal Material SUS316/SUS304/ CARBON STEEL ,ETC Heating Source Steam / Electrical / Natural Gas / Diesel / Etc
Capacity 10-10000kg Per Hour Water Evaporation 5-5000kg Per Hour
Temp 120-600'C Particle Per Hour
High Light

spray drying plant


spray drying equipment


foodstuff spray drying equipment

Leave a Message
Product Description

Stevia SUS304 SU316 LPG Series High speed


Centrifugal  Spray Drying Equipment for foodstuff


Performance characteristics of used spray dryer for sale

1.Drying speed is fast, solid-liquid surface area greatly increased after the spraying in the hot air flow, the moment

can be evaporated moisture of 95% -98%, and only a few seconds to complete the drying time, especially for

heat-sensitive materials drying.

2.The product has good uniformity, mobility and solubility products of high purity, good quality.

3.The production process is simplified, convenient control. For special materials for a moisture content of

40-60% (90%) of the liquid can be dried into a powder or grain products, after drying without crushing

and screening, to reduce the production processes, to improve product purity.

4.On product particle size, bulk density, moisture, within a certain range by changing the operating conditions to

adjust, control and management is easy.

Stevia LPG Series High speed Centrifugal  Spray Drying Equipment for foodstuff 0

Technical Requirements of used spray dryer for sale

  • 1.1 drying parameters
  • Air inlet temperature: 180 ℃
  • Air outlet temperature: 75 ~ 80 ℃
  • Can spray volume: 300kg / h
  • Dewatering capacity: 100kg / h
  • Heating:Gas+electric
  • 1.2 Power Requirements: Voltage: 380V 3 phase 50Hz
  • 1.3 Exhaust emptying dust content ≤ 50mg/m3 standard dry air
  • 1.4 site conditions
  • Factory site:
  • Atmospheric pressure: 760mmHg
  • Ambient temperature: ≥ 0 ℃
  • Relative humidity: 60%


Feature :

The drying speed is high when the material liquid is atomized, the surface area of the material will increase greatly. In the hot-air flow, 95%-98% of water can be evaporated at a moment. The time of completing the drying is only several seconds. This is especially suitable for drying the heat sensitive materials. Its final products own the good uniformity, flow ability & solubility. And the final products are high in purity and good in quality. The production procedures are simple and the operation and control are easy. The liquid with moisture contents of 40-60% (for special materials, the contents might be up to 90%.)can be dried into the powder or particle products once a time. After the drying process, there is no need for smashing and sorting, so as to reduce the operation procedures in the production and to enhance the product purity. The product particle diameters, looseness and water contents can be adjusted through changing the operation condition within a certain range.

ed centrifugal sprayer on the top of the tower, the material liquid will rotate and be sprayed into the extremely fine mist liquid beads. Through very short time of contacting the heat air, the materials can be dried into the final products. The final products will be discharged continuously from the bottom of the drying tower and from the cyclones. The waste gas will be discharged from blower.

Stevia LPG Series High speed Centrifugal  Spray Drying Equipment for foodstuff 1

  1. YIBU conventional Spray Dryer turns liquid into powder in a highly efficient manner. It is used within fields as diverse as the dairy, food and chemicals industries where it has won renown for its performance. With more than 2,500 spray dryers installed worldwide, YIBU Dryer combines experience and cutting-edge technology into added-value solutions for its customers.
  2. Designed for the specific product to be dried in compliance with a given industry’s standards and requirements, the conventional Spray Dryer produces a fine powder with particle sizes between 20-300 my. It is primarily applied in the chemical industry, but it has also proved valuable in the production of food and dairy products.
  3. Atomization of the concentrate takes place via either a Rotary Atomizer or high-pressure nozzles. The drying air enters through the air disperser at a high velocity, ensuring optimal mixing with the atomized concentrate. Evaporation is instantaneous, taking place as the droplets pass through the drying chamber.
  4. Complete control of moisture content, particle structure, particle size distribution, solubility, and wettability, and retention of natural aromas and flavours.
  5. Unbeatable performance/cost ratio Energy efficient components, continuous and rapid drying, ease of operation and process automation provide complete control over yield and costs.
Type LPG
5 25 50 100 150 200-3000
Inlet temperature ≤ 350°C
Outlet temperature 80-90°C
evaporate capacity (kg/h) 5 25 50 100 150 200-3000
driving type compressed air drive mechanical drive
Rotate speed 25000 22000 21500 18000 18000 15000
diameter of atomizer tray (mm) 50 120 120 120 150 180-340
heating source electricity electricity electricity +steam+fuel oil+coal gas electricity +steam electricity +steam+fuel oil+coal gas To be solved by users
Electric-heating power (kw) 9 45 60 81 99
Dried powder recovery rate (%) ≥ 95 ≥ 95 ≥ 95 ≥ 95 ≥ 95 ≥ 95
Installation size A(mm) 1000 1290 1730 2500 2800 according to practical needs
B(mm) 2100 3410 4245 5300 6000
C(mm) 2300 4260 4645 6000 6700
φ D(mm) 1060 1800 2133 2560 2860
E1(mm) 1050 1200 1640 2100 2180
E2(mm) 1050 1200 1640 2100 2180
F(mm) 750 1000 1250 1750 1970
G(mm) 530 1700 1750 1930 2080
H(mm) 530 1300 1800 2600 3050
I(mm) 530 1550 1600 1780 1960




Stevia LPG Series High speed Centrifugal  Spray Drying Equipment for foodstuff 2
