Stainless Steel 316L EAC 100kg/H Spray Drying System

Stainless Steel 316L EAC 100kg/H Spray Drying System

  • High Light

    316L Spray Drying System

    ,

    EAC Spray Drying System

    ,

    100kg/H Spray Drying System

  • Material
    SUS316L
  • Dust Collecting
    Bag Filter +cyclone
  • Heating
    Steam Heating
  • Name
    316L Spray Drying System
  • Place of Origin
    CHINA
  • Brand Name
    YIBU
  • Certification
    CE / UL / SGS / EAC / CR – TU
  • Model Number
    LPG
  • Minimum Order Quantity
    1 set
  • Price
    20000~800000USD/set
  • Packaging Details
    Fumigation Woodencase
  • Supply Ability
    500sets

Stainless Steel 316L EAC 100kg/H Spray Drying System

316L LPG Model Centrifugal Atomizer Type Industrial Food Spray Dryer with steam heating system







LPG Food Spray Dryer Description

YIBU food Spray dryer is a wide applied process in liquid process shaping and drying industry. Particularly it is suitable for producing powder, granule or block solid product from solution, emulsion, suspending liquid and pumped paste liquid. Therefore when the distribution of granule size, final moisture, bulk density, granule shape of finished product must be conformed to accuracy standard, the spray drying is an ideal process.

Stainless Steel 316L EAC 100kg/H Spray Drying System 0



LPG Industrial Spray Dryer Application

It's widely used in foodstuff, pharmaceutical and chemical industrial, such as egg powder, amino acid product, protein, blood, food flavor, food ingredients, pectin, carrageenan, spirulina, herbal extraction, pigment, cocoa, mushroom, PAC, malt dextrin, collagen, juice, yeast, Coffee, Creamer, coconut, milk, gelatin, gum and acacia etc.



LPG Working Principle of Food Spray Dryer

After filtering and heating, the hot fresh air enter into the air distributor at the top of drying chamber, distributed in spiral way uniformly from up to down. At the same time, the feeding liquid is pumped to the top atomizer, then be sprayed to extremely fine mist liquid drop. Through the short time of direct contact with hot air, the moisture evaporated at once, the solid remains to be powder. The dry powder will be discharged continuously from the bottom of drying tower and cyclone collector, the exhaust air will be discharged after cleaning.



LPG Industrial Spray Dryer Technical parameters

Model Food / Industrial Spray Dryer MODEL LPG-
5 25 50 100 150 200-5000
Inlet air temperature ≤ 350°C
Outlet air temperature 80-90°C
Evaporate capacity (kg/h) 5 25 50 100 150 200-5000
Atomizer type compressed air drive mechanical drive
Rotary speed 25000 22000 21500 18000 18000 15000
Diameter of atomizer disc (mm) 50 120 120 120 150 180-500
Heating source Electricity

Electricity/LPG/

Natural gas/Oil/Steam

Electricity/LPG/

Natural gas/Oil/Steam

Electricity/LPG/

Natural gas/Oil/Steam

Electricity/LPG/

Natural gas/Oil/Steam

Electricity/LPG/

Natural gas/Oil/Steam

Electric-heating power (kw) 9 - - - - -
Dry powder yield (%) ≥ 95 ≥ 95 ≥ 95 ≥ 95 ≥ 95 ≥ 95



Successful Experience Overseas of YIBU LPG Industrial Food Spray Dryer

LPG food/ industrial spray dryer has a very mature technology and process, and YIBU company has rich overseas site installation experience and good after sale service .
