SUS304 high speed centrifugal Spray Drying Machine For Processing Maltodextrin Liquid Into Powder

SUS304 high speed centrifugal Spray Drying Machine For Processing Maltodextrin Liquid Into Powder

  • High Light

    spray drying plant

    ,

    food dryer machine

    ,

    SUS304 centrifugal spray drying machine

  • Material
    All Parts Are In SUS304 ,SUS 316L ,or Only MOC IsSUS304 SUS16L, The Rest Are Carbon Steel
  • Heatsource
    Steam ,electricity ,gas Furance And So On
  • Product Collecting
    Cyclone ,bag Filter And Water Scrubber
  • Size
    Depending On The Size Of Machine
  • Application
    Used For Processing The Liquid Material Into The Powder
  • Air Inlet System
    We Can Customize It According To Customer Requirements
  • Place of Origin
    China
  • Brand Name
    YIBU
  • Certification
    CE,Ghost,UL
  • Model Number
    LPG
  • Minimum Order Quantity
    1 set
  • Price
    Negotiation
  • Packaging Details
    wooden case

SUS304 high speed centrifugal Spray Drying Machine For Processing Maltodextrin Liquid Into Powder

MaltodextrinLPG Series High speed Centrifugal Spray Dryer

Product Description

LPG Model High-speed  spray dryer is the technology most widely used in the liquid technology shaping and in the drying industry. The drying technology is most suitable for producing solid powder or particle products from liquid materials, such as: solution, emulsion, suspension and pumpable paste states ,For this reason, when the particle size and distribution of the ­final products, residual water contents, mass density and the particle shape must meet the precise standard, spray dryer drying is one of the most desired technologies.



Main Features

1. Different types of solution, suspension, emulsion and cream paste material can be dry for a one-time production.
2. The fog moment and fog droplet of spray-drying can be slightly adjusted.
3. The hot air has been reasonable allocation, and the ceiling and walls sticky situation has been eliminated.
4. It is suitable for the drying of thermo-sensitive and non thermo-sensitive material at the same time. The product particles are smaller than pressure spray dryer.
5. Simplify the production process, easy to use, good liquidity and instant of the product.

Work Principle

LPG Model High-speed Spray Dryer is gas-liquid co-current flow drying equipment, using high-speed centrifugal atomizer, the liquid will be atomized into fine droplets, then mix with the hot air from the distributor in the dryer, heat and mass transfer exchanges rapidly during the mixing process. In a very short period of time the liquid become dry powdered products. Production control and product quality control is convenient and reliable. It is widely used in the drying production of different types of liquids materials.

Material to be dried

1. Inorganic: aluminum nitride, zirconia, potassium fluoride, bentonite, kaolin, barium sulfate, lead sulfate, sodium aluminum, chromium oxide, titanium dioxide.
2. Macromolecule polymers: urea-formaldehyde resin, PVC.
3. Dyes: dispersol red FB, reactive dyes, etc.
4. Chemical Agents: silica dioxide, diatomite, sodium silicate, wood calcium, sodium ligninsulfonate, naphthalene series water reducer.
5. Pesticide: carbendazol chloride wettable power.
6. Food and feed additives: casein peptide phosphate, potassium sorbate, fish serum.
7. Fertilizer: potassium humate, sodium humate.



SUS304 high speed centrifugal Spray Drying Machine For Processing Maltodextrin Liquid Into Powder 0



Technical Data:

specification LPG
5 25 50 100 150 200-3000
Tep of inlet air less than 350°C
Tep of outlet air 80-90

(kg/h)

Evaporated capacity

5 25 50 100 150 200-3000
Transmitted Compressed air By machine
(rpm)Rotating speed 25000 22000 21500 18000 18000 15000

(mm)

ia. of atomizing disk

50 120 120 120 150 180-340
Heat source Electricity Electricity

+

Electricity+ steam, oil fuel, gas

+ Electricity+ steam + Electricity+ steam, oil fuel, gas Solved by customer

(kw)

Powder of electric heater

9 45 60 81 99

(%)

Yield of dry powder (%)

≥95 ≥95 ≥95 ≥95 ≥95 ≥95
Installation Size for reference A(mm) 1000 1290 1730 2500 2800 Decided in accordance with actual condition
B(mm) 2100 3410 4245 5300 6000
C(mm) 2300 4260 4645 6000 6700
φ D(mm) 1060 1800 2133 2560 2860
E1(mm) 1050 1200 1640 2100 2180
E2(mm) 1050 1200 1640 2100 2180
F(mm) 750 1000 1250 1750 1970
G(mm) 530 1700 1750 1930 2080
H(mm) 530 1300 1800 2600 3050
I(mm) 530 1550 1600 1780 1960
